Forest Haven

Nordic Spruce – natural wood – untreated

Materials we include:
1 – Wall logs, standard log house parts (44 / 70 / 44xGAPx44 mm thickness);
2 – Insulation beams (43 mm width x 100 mm thickness);
3 – Boards (43 mm width x 25 mm thickness);
4 – Tongue & Groove boards (105 mm width x 19 mm thickness).

Materials we do not include:
5 – Vapor barrier film;
6 – Insulation material;
7 – Diffusion membrane;
8 – Protective grille.

Note – For most cases vertical insulation beams (2) will be precut to the required length; however, horizontal ones must be cut during the assembly process. Boards (3) and cladding boards (4) comes in 6000 mm lengths and must also be cut to the required sizes during assembly.

Key benefits of fibre cement cladding
Fibre cement cladding offers several unique benefits that make it a popular choice for building exteriors. Here are three key advantages of fibre cement cladding:

Durability and Weather Resistance: Fibre cement cladding is highly durable and designed to withstand harsh weather conditions. It is composed of a mixture of cement, cellulose fibers, and additives, resulting in a strong and resilient material. Fibre cement cladding is resistant to moisture, rot, insect infestation, and UV radiation. It does not warp, crack, or peel over time, maintaining its integrity and appearance even in extreme climates. This durability makes fibre cement cladding a long-lasting solution, reducing the need for frequent repairs or replacements.

Fire Resistance: Fibre cement cladding is inherently fire-resistant, making it an excellent choice for buildings where fire safety is a concern. The cement component of fibre cement cladding acts as a fire barrier, preventing the spread of flames and limiting fire damage. It has a high fire rating and can help to protect the building and its occupants in the event of a fire. Using fibre cement cladding can enhance the overall fire safety of a structure and may even contribute to meeting building code requirements and regulations.

Low Maintenance: Fibre cement cladding is known for its low maintenance requirements. It does not require regular painting, staining, or sealing like some other cladding materials. The material is resistant to fading, discoloration, and mould growth. A periodic cleaning with mild soap and water is usually sufficient to keep fibre cement cladding looking fresh and well-maintained. This low-maintenance characteristic not only saves time and effort but also reduces ongoing maintenance costs over the lifespan of the building.

Materials we include:
1 – Cedral Lap cladding boards (190 mm width x 10 mm thickness);
2 – Boards (43 mm width x 25 mm thickness);
4 – Insulation beams (43 mm width x 100 mm thickness);
8 – Wall logs, standard log house parts (44 / 70 / 44xGAPx44 mm thickness).

Materials we do not include:
3 – Protective grille;
5 – Diffusion membrane;
6 – Insulation material;
7 – Vapor barrier film.

Note – For most cases vertical insulation beams (4) will be precut to the required length; however, horizontal ones must be cut during the assembly process. Boards (2) comes in 6000 mm length and Cedral Lap boards (1) comes in 3600 mm length and must also be cut to the required sizes during assembly.

Nordic Spruce – natural wood – untreated

Materials we include:
1 – Wall logs, standard log house parts (44 / 70 / 44xGAPx44 mm thickness);
2 – Insulation beams (43 mm width x 100 mm thickness);
3 – Boards (43 mm width x 25 mm thickness);
4 – Tongue & Groove boards (105 mm width x 19 mm thickness).

Materials we do not include:
5 – Vapor barrier film;
6 – Insulation material;
7 – Diffusion membrane;
8 – Protective grille.

Note – For most cases vertical insulation beams (2) will be precut to the required length; however, horizontal ones must be cut during the assembly process. Boards (3) and cladding boards (4) comes in 6000 mm lengths and must also be cut to the required sizes during assembly.

Nordic Spruce – natural wood – untreated

Materials we include:
1 – Wall logs, standard log house parts (44 / 70 / 44xGAPx44 mm thickness);
2 – Insulation beams (43 mm width x 100 mm thickness);
3 – Boards (43 mm width x 25 mm thickness);
4 – Cladding boards (without T&G, 110 mm width x 19 mm thickness).

Materials we do not include:
5 – Vapor barrier film;
6 – Insulation material;
7 – Diffusion membrane;
8 – Protective grille.

Note – For most cases vertical insulation beams (2) will be precut to the required length; however, horizontal ones must be cut during the assembly process. Boards (3) and cladding boards (4) comes in 6000 mm lengths and must also be cut to the required sizes during assembly.

SONATA QUADRILLE Premium Bitumen Shingles

Product Overview

The PREMIUM grade series of bituminous shingles is tailored to meet the needs of discerning customers who prioritize unwavering quality and confidence in their roofing materials. This line of products features improved physical and mechanical characteristics, guaranteeing increased durability even in colder temperatures. The inclusion of a self-adhesive layer not only facilitates a seamless roof covering but also affords maximum protection against formidable wind gusts.

SONATA QUADRILLE is a traditional monochrome bitumen shingle made from high-quality SBS modified bitumen with protective granule coating. These shingles combine elegant simplicity with exceptional durability.

Key Features

Performance Benefits:

• Superior cold weather flexibility and crack resistance
• Self-adhesive layer for seamless installation and wind protection
• Excellent sound insulation properties
• UV-resistant granules maintain color stability
• Extended service life with long warranty period

Design & Aesthetics:

• Clean, monochrome appearance adds subtle sophistication
• Creates beautiful spatial effect and modern roof profile
• Complements various architectural styles

Installation Advantages

• Easy and economical installation with minimal waste
• No removal needed for replacement – existing shingles serve as additional waterproofing
• Convenient transportation and handling

Why Choose SONATA QUADRILLE

These premium shingles are ideal for homeowners seeking uncompromising quality, timeless elegance, and long-term value. The combination of traditional design, advanced SBS modified bitumen technology, and improved mechanical properties ensures reliable protection and aesthetic appeal for years to come.

Perfect for those who prioritize durability, ease of maintenance, and confidence in their roofing investment.

Roof Panels with a Standing Seam

The edge finish option with cut edges allows for assembly on the start strip. The edges are cut on two sides of the panel, enabling you to rotate the panel based on the assembly direction. The PD510 Nano panel is available only with cut edges.

Installation

Roof panels with seams should be installed at positive temperatures. Protective foil is applied to safeguard the roof panels from mechanical damage. It should be removed immediately during the assembly process and it should protect the panels from humidity and sun exposure during the storage period. Not following these guidelines may make it difficult to remove the foil later and can lead to dirt accumulation from the adhesive.

Maintenance

Generally, roofs consisting of standing seam panels do not require special maintenance. However, to prevent rapid damage to the building, it is essential to inspect and maintain both wall and roof coverings at least once a year, regardless of their location. Any deposits or industrial dust (such as from lime plants, cement, foundries, and mines) that could damage the varnish due to chemical reactions with water, as well as leaves that can cause fading through rotting, should be removed from the panel surface. Any deficiencies in the coating should be cleaned and repainted using specialized touch-up paints.

Final Warnings

1. Use special electric vibrating scissors, irregular nibblers, or hand scissors to cut sheets. Do not use tools that can damage the varnish and galvanized coating, such as angle grinders, which produce heat when cutting steel.
2. You may walk on the roof wearing shoes with soft soles, taking care to step on the bottoms of the waves or on patches. Ensure that all screws are tightened before walking on the roof.
3. Small damages to the coating from assembly can be touched up with paint. Ensure the surface is cleaned of dirt and oil before applying.
4. Remove steel chips from cutting or drilling with a soft brush, as rust from these chips can damage the steel surface.
5. Dirt resulting from assembly work or regular use should be cleaned using standard cleaning agents.
6. The use of any steel treatments (including chimney caps, rainwater cleaners, etc.) made from copper sheets on roofs and elevations comprising galvanized and coated sheets is prohibited.

The left side of the image shows a fully insulated roof, while the right side shows only the materials we include.

Materials we include:
1 – First layer of roof boards (105 x 19 mm)
2 – Insulation beams (100 mm height x 43 mm thickness)
4 – Second layer of roof boards (105 x 19 mm)

Materials we do not include:
3 – Insulation material

Note: Insulation beams will be provided slightly longer and must be cut during the assembly process. The number of beams will be based on standard spacing, with 550 mm gaps between them.

The left side of the image shows a fully insulated roof, while the right side shows only the materials we include.

Materials we include:
1 – First layer of roof boards (105 x 19 mm)
2 – Insulation beams (100 mm height x 43 mm thickness)
3 – Boards (43 x 25 mm)
4 – Boards (125 x 22 mm)

Materials we do not include:
5 – Vapor barrier film
6 – Insulation material
7 – Diffusion membrane

Note: Insulation beams will be provided slightly longer and must be cut during the assembly process. The number of beams will be based on standard spacing, with 550 mm gaps between them.

Timber Frame Base for Log Cabins

A timber frame base is a wooden foundational structure that elevates your log cabin above ground level, creating a stable, level platform while protecting against moisture damage. This base system typically sits on concrete pads or posts, uses pressure-treated timbers for durability, and provides robust support for the cabin’s walls and flooring system.

Key Benefits

Simplified leveling on uneven terrain
Enhanced air circulation beneath the structure
Protection against ground moisture
Cost-effective alternative to concrete foundations
Note: Regular maintenance required to ensure longevity

Why Choose a Timber Frame Base?
Timber frame bases offer distinct advantages over traditional concrete foundations:
Portability – Structure can be relocated if needed
Versatility – Perfect for sites where concrete pouring isn’t feasible
Cost-effective – More affordable than concrete foundations
Superior ventilation – Improved airflow minimizes wood rot risk

Foundation Requirements

Timber frame bases must be placed on stable, solid foundations to maintain structural integrity.

Acceptable Foundation Options:
Compacted gravel or crushed stone bed
Concrete blocks or paving slabs (minimum 500 x 500 mm)
Metal or concrete pile systems
Adjustable support posts on solid foundations

Unsuitable Surfaces:
Never place timber frame bases directly on:
Lawn or grass
Sand
Loose or uncompacted soil
Any soft or unstable ground

Included Components:

• Item 2: Timber frame base beams
o Height: 100mm or 150mm
o Thickness: 43mm (external beams doubled to 86mm total)
• Item 4: Base beams (standard log house components)
• Item 5: Wall logs (standard log house components)

Customer-Supplied Materials:

• Item 1: Solid foundation system
• Item 3: Breathable membrane barrier

PVC Doors and Windows:

A Modern Alternative for Log Homes

While traditional wooden doors and windows remain the classic choice for log homes, PVC options offer a practical alternative worth considering for your project.

Making Your Choice

The decision between PVC and wooden doors and windows ultimately depends on your priorities. Choose PVC if you value low maintenance, long-term durability, and energy efficiency. Option for traditional wood if authentic appearance and natural materials are your primary concerns. Many log home owners successfully incorporate PVC elements while maintaining the overall charm and character of their homes.

Consider consulting with your architect or builder to determine which option best aligns with your specific needs, local climate conditions, and aesthetic preferences.

Key Advantages of PVC

Minimal Maintenance Requirements Unlike wooden frames that need regular painting, staining, and sealing every few years, PVC doors and windows are virtually maintenance-free. A simple occasional cleaning is all that’s needed to keep them looking their best throughout their lifespan.

Enhanced Durability PVC frames resist common issues that affect wood, including rot, warping, swelling, and pest damage. They maintain their structural integrity regardless of weather conditions, making them particularly suitable for homes in challenging climates.

Superior Energy Performance Modern PVC windows and doors typically offer excellent thermal insulation properties, with multi-chamber profiles and advanced sealing systems that can reduce heat loss and minimize noise transmission. This can translate to lower heating and cooling costs over time.

Cost Considerations While initial investment may vary, the reduced maintenance costs over the lifetime of PVC products often result in long-term savings compared to wooden alternatives.

Design Flexibility

Today’s PVC options come in various colors and finishes, including convincing wood-grain textures that can complement the rustic character of log construction. Many manufacturers offer customization options to match your specific architectural vision.

Why Choose Professional Assembly? Your Dream Log Cabin, Built Right

Transform Your Vision into Reality – Without the Stress

Imagine watching your beautiful log cabin come to life in just a few days, assembled with precision by skilled craftsmen who’ve perfected their art through years of experience. That’s the peace of mind our professional assembly service delivers.

✓ From Delivery to Completion – We Handle Everything

Our comprehensive service includes:

• Foundation preparation
• Wall assembly
• Roof installation
• Final finishing touches
• Complete site cleanup

You simply choose your cabin and schedule the installation. We handle the rest.

WHY CHOOSE OUR ASSEMBLY SERVICES?

1. Experienced Teams – Specialized in log cabin construction
2. Regional Coverage – Service available across regions
3. Flexible Scheduling – Work around your timeline
4. Quality Guarantee – Professional standards assured
5. Transparent Pricing – No hidden costs
6. Complete Solutions – From foundation to finishing

✓ Time is Precious – We Give It Back to You

While DIY assembly can take weeks of your valuable time, our expert team completes your cabin installation in just days. Skip the frustration of deciphering complex instructions and spend your time planning how you’ll enjoy your new space instead.

✓ Quality That Stands the Test of Time

Every beam, every joint, every seal matters. Our professionals ensure:

• Precise fitting of all elements for maximum structural integrity
• Superior moisture protection that prevents costly water damage
• Expert foundation preparation that prevents settling and structural issues
• Aesthetic perfection that enhances your property value

✓ Your Investment, Protected

A log cabin is a significant investment. Why risk costly mistakes? Incorrect assembly can lead to:

• Roof problems and leaks
• Structural subsidence
• Premature wear and damage
• Voided warranties

Our professional installation eliminates these risks, protecting your investment for decades to come.

✓ Surprisingly Affordable Peace of Mind

Professional assembly is more cost-effective than you might think. When you factor in:

• The tools you won’t need to buy or rent
• The time you’ll save
• The mistakes you’ll avoid
• The long-term durability you’ll gain

…our assembly service becomes an investment that pays for itself.

Your log cabin should be a source of joy, not stress. With our professional assembly service, you get a perfectly constructed cabin that will provide comfort and value for generations – all without lifting a finger.

Ready to make your log cabin dream a reality? Choose professional assembly and enjoy your new space sooner, safer, and stress-free.
